Our soft system hologram embossing machine is designed for producing anti-counterfeit holographic films which are extensively used in flexible packaging industries.
Firstly, to etch desired patterns on a metallic nickel plate. Then our soft system holographic embossing machine functions to transfer the patterns on the plate onto various packaging materials, like BOPP film, coated PET films, PVC materials, and more. Thus we will be able to obtain desired anti-counterfeit packaging materials.
Model | |||
Embossing width | 800mm | 1000mm | 1200mm |
Plate perimeter | 520mm | 520mm | 520mm |
Embossing speed | 60m/min | 60m/min | 60m/min |
Un./rewinding diameter | 500mm | 500mm | 500mm |
Material thickness | 12-100micron | 12-100micron | 12-100micron |
Voltage | 380v, 50Hz or special made | 380v, 50Hz or special made | 380v, 50Hz or special made |
Power | 12kw | 15kw | 18kw |
Air pressure | 3kg | 4.5kg | 5kg |
Counter | 0-9999m | 0-9999m | 0-9999m |
Machine weight | 3t | 3 t | 3.5 t |
Machine dimension | 2200 × 2000 × 1750mm | 2200 × 2200 × 1750mm | 2200 × 2600 × 1750mm |
As a soft system holographic embossing machine manufacturer based in China, we not only provide hologram machine, but die cutting slotting machine, plastic injection molding machine, printing machine, laminating machine, and much more.
